Specifications
| Connection: | Thread ends BSPP - ISO228/1 |
| Butt weld ends - EN12627 (WCB), DIN2463 / ISO1127 (SS316) | |
|
|
Socket weld ends - ASME B16.11 |
|
|
Flanged ends - EN1092, ASME B16.5 |
| Size range: | 1/4”-4” DN8-DN100 |
| Pressure rating: | 1/4”-1”: FB = 2000psi |
| 1 1/4”-2”: FB = 1500psi | |
| 2 1/2”-4”: FB = 1000psi | |
|
|
Pressure rating for flanged valves will be according to nominal pressure for flange. |
| Body: | WCB, CF8M |
| End cap: | WCB, CF8M, CF3M (for BW ends, CF8M valves) |
| Seat: | PTFE with 25% carbon |
| Operation: | Hand lever, pneumatic actuator, electric actuator |
Features
